Concept
Recessed LED Downlight in a trim or trimless version.Material
Die-cast black painted anodised aluminium heat sink.
Reflective metallised thermoplastic material reflector with high luminous efficiency and visual comfort.
Silicone sealing kit for water and dust protection.
Available in a trim version with an integrated black or white ring or a trimless version with a load-bearing element for installation and finishing in plasterboard.Source
High efficiency Ra90 LED Chip on Board.
Ra80 on request.Optic
Two different optics: low luminance deep UGR for high visual comfort and VWFL for wide coverage with excellent uniformity of luminance.
UGR Optic: composed of a deep thermoplastic reflector with reflective metallisation and a protective anti-scratch coating, a holographic acrylic diffuser screen and a highly reflective white thermoplastic internal recuperator.
UGR<19 and L65<1000 cd/m² (EN 12464-1).
VWFL Optic: with high luminous efficiency composed of a deep thermoplastic reflector with reflective metallisation and a protective anti-scratch coating, a holographic acrylic diffuser screen and a highly reflective white thermoplastic internal recuperator.
IP54 protection for the visible parts of the installed fixture.Installation
Quick tool-free mounting system for false ceiling installation from 0.5 to 30mm.Power Supply
Integrated electronic or DALI driver.
220-240Vac 50/60HzNotes
Casambi control system available using a dedicated accessory (only for DALI version products).
110-277Vac version available on request.
